Adjustment Type:

• Push Button

Connection Type:

• Connector, 5-pin M12 pigtail

Housing Type:

• Rectangular

Supply Voltage:

• 10 to 30 VDC
• Polarity Protected

Current Requirements:

• 50mA (exclusive of load)

Output Transistors:

• (1) NPN and (1) PNP sensor output transistor:
  NPN: Sink up to 150mA
  PNP: Source up to 150mA
• Continuous short-circuit protection
• Outputs protected from pulsing during power up

Remote AUTOSET Input

• Opto-isolated momentary sinking input (10mA)

Response Time:

• Light State = 100 microseconds
• Dark State = 100 microseconds

LED Light Source:

• Red 660nm
• Pulse modulated

Push Button Control:

• "One-Touch" AUTOSET pushbutton setup
• Tweak adjustments with "up" or "down" buttons
• LST (Light State Tracking) Enable/Disable
• Light "ON"/Dark "ON" Selection

Range:

• Optimum from 6in. to 8ft. (15.24cm to 2.4m) distance to the AR6151 reflector

Hysteresis:

• Two bars as displayed on Contrast Indicator
  Light State Switch = 5
  Dark State Switch = 3

Light Immunity:

• Responds to sensor's pulse-modulated light source, resulting in high immunity to most ambient light, including high intensity strobes

Diagnostic Indicators:

• Contrast Indicator - Display scaled reading of sensor's response to contrasting light levels (light vs. dark) on an 8-bar LED display
• Red LED Indicator - LOCK
• Green LED Indicator - LST (Light State Tracking)
• Red LED Indicator - OUTPUT

NOTE: IF Output LED flashes, a short circuit condition exists

Ambient Temperature:

• -40°C to 70° (-40°F to 158°F)

Rugged Construction:

• Chemical resistant, high-impact polycarbonate housing
• Waterproof ratings: NEMA 4, IP66
